Good Properties Long Carbon Chain Nylon PA1010 Used for Personal Articles Industry Teeth Brush, Nail Polish Brush, Makeup Brush with Best Factory price!
Product Description
PA1010 is made of pure green plant castor seed as raw material. Is a translucent, light and hard, bright surface of crystalline white or yellowish particles, relative density and water absorption than PA6, PA66 lower, higher than 100ºC, long-term contact with oxygen will gradually appear yellowish brown, while mechanical strength decline.
Widely used in automobile, instrument, brush making, shipbuilding, printing and dyeing, textile, railway, mining, oil, household appliances and other fields.
Product Description
Detailed Photos
TDS Sheet
| TYPICAL PROPERTIES | CONDITION | STANDARD | UNIT | VALUE |
| PHYSICAL PROPERTIES | ||||
| Density | ISO 1183 | [g/cm³] | 1.05 | |
| Moisture absorption | T=23°C / 50%RH | ISO 62 | [%] | 0.5 |
| Mold shrinkage parallel | long. | ISO 294 | [%] | 1.0 |
| Mold shrinkage transverse | trans. | ISO 294 | [%] | 1.3 |
| RHEOLOGICAL | ||||
| Viscosity number | ISO307 | [ml/g] | 2.4 | |
| MECHANICAL PROPERTIES | ||||
| Tensile modulus | 1 mm/min | ISO 527 | [MPa] | 1600 |
| Tensile stress at break | 50 mm/min | ISO 527 | [MPa] | 60 |
| Tensile strain at break | 50mm/min | ISO 527 | [%] | 200 |
| Flexural strength | 2 mm/min | ISO 178 | [MPa] | 60 |
| Flexural modulus | 2 mm/min | ISO 178 | [MPa] | 1200 |
| Charpy notched | +23 °C | ISO 180/1A | [kJ/m²] | 10 |
| Charpy notched | - 30 °C | ISO 180/1A | [kJ/m²] | 9 |
| Shore hardness(D) | ISO 868 | 75 | ||
| THERMAL PROPERTIES | ||||
| Heat Deflection Temperature | 0.45MPa | ISO 75 | [°C] | 155 |
| Melting point | DSC | ISO 11357 | [°C] | 202 |
| BURNING BEHAVIOUR | ||||
| Flammability(UL94) | 0,8 mm | ISO 1210 | [Class] | HB |
| Burning rate (FMVSS) | FMVSS 302 | [mm/min] |
Product Description
PA1010 is made of pure green plant castor seed as raw material. Is a translucent, light and hard, bright surface of crystalline white or yellowish particles, relative density and water absorption than PA6, PA66 lower, higher than 100ºC, long-term contact with oxygen will gradually appear yellowish brown, while mechanical strength decline.
Widely used in automobile, instrument, brush making, shipbuilding, printing and dyeing, textile, railway, mining, oil, household appliances and other fields.
Physical Properties
Polyamide 1010 (PA1010) is a translucent, light and hard, bright surface crystalline white or slightly yellow particles, relative density and water absorption than PA6, PA66 lower, high mechanical strength, impact toughness, wear resistance and self-lubrication good, has good sound attenuation; Good chemical resistance, non-toxic, insoluble in hydrocarbons, esters and low alcohols, concentrated sulfuric acid; Resistance to mold, bacteria and insects, with good electrical insulation; The melt has good fluidity and is easy to form, but the melt temperature range is narrow, and it is easy to be oxidizing and degraded. When it is higher than 100ºC, it will gradually show yellowish brown in contact with oxygen for a long time, and its mechanical strength will decrease.
| High mechanical strength | Good impact toughness |
| Wear resistance and self-lubrication | Good noise reduction |
| Good oil resistance | Alkali resistance |
| Chemical resistance | Insoluble in hydrocarbons |
| Esters and lower alcohols | Resistant to mold |
| Bacteria and Moth-eaten | Good electrical insulation |
| Good melt fluidity, easy to form |
Application
Widely used in automobile, instrument, brush making, shipbuilding, printing and dyeing, textile, railway, mining, oil, household appliances and other fields.
| Building Material Industry | Marble Slab , Abrasive Brush |
| Automotive Industry | Oil Tube |
| Petroleum Industry | High Pressure Tube |
| New Energy Source Industry | Solar Energy, Power Generation |
| Electronics&Electrical Industry | 5G Communication |
| Smart Wearable | Shoe Material, Shoe Arch |
| Aerospace | UAV(Unmanned Aerial Vehicle) |
| Consumption Industry | Wiring Harness |
| Personal Articles Industry | Toothbrush |
PA1010 plastic products can replace metal and non-ferrous metals to make a variety of mechanical parts, motor parts and high pressure seals. Such as injection molding gear can be used as instruments, textile, automotive and printing and other mechanical equipment accessories, but also for bearing ball bracket, shaft sleeve, small worm reducer, oil pipeline and cable sheath and film, powder for metal surface anti-corrosion, wear-resistant coating.
Long carbon chain nylon has the characteristics of corrosion resistance, pressure resistance, oil resistance, cold resistance, small expansion coefficient of fuel and so on. It is an ideal material for the manufacture of automobile tubing. 60-70% of long carbon chain nylon in developed countries is used in the production of automotive hoses, such as brake tubes, pipelines, clutch hoses, etc. Long carbon chain nylon can also be used for silencing gears, bearings, thrust pads, seismic components, wipers and so on.
